50″ Light Bar System 160 W 8 LED Lights
With KC’s Jeep Wrangler JL / Gladiator JT Overhead Brackets and Gravity® LED Pro6 light bar over the windshield of your Jeep Wrangler JL or Jeep Gladiator JT, your rig will be taken to the next level. With a fully bolt-on design, these mount securely to factory locations and include upgraded hardware. This kits also include a-pillar brackets for a well-rounded lighting setup. Also includes the full wiring harness with switch, and silicone protectors that go in between the bracket and the vehicle to protect your Jeep’s paint.
NOTE: Does not fit Jeep 4xe, Mojave, Sand Runner or 392 Editions
The KC Gravity® LED Pro6 Light Bar is an industry first, allowing users to be in full control of their lighting needs. Featuring KC’s patented Infinity Ring™ System, the Pro6 LED light bar is modular, expandable, and adjustable. The Infinity Ring™ system via its unique hinge design allows users to easily transform the Pro6 light bar between a straight and curved orientation, with adjustable widths between 20″- 57″. Every Pro6 system is powered by a chain of individual, 20W Gravity LED Pro6 inserts which take advantage of KC’s patented Gravity Reflective Diode technology. This translates to unparalleled light clarity, output, low amp draw, and a usable beam pattern. If you are looking for the ultimate performance led light bar for your Jeep, Truck or UTV, KC’s Pro6 LED light bar system has you covered. All Pro6 LED Light Bars are priced with vehicle specific mounting kits (Pro6 Universal LED Light Bars do not come with mounts).
- Pro6 patented Infinity Ring™ System: Easily transform the Pro6 light bar between straight or curved light orientations
- Every Pro6 is powered by KC patented Gravity® Reflective Diode(GRD) technology for unparalleled beam shape, light performance, and clarity
- Gravity® G6 LED reflector optics utilizing a combination of Driving and Wide-40 Beam pattern lights for optimal lighting balance and performance
- Modular design is expandable to different size widths and beam patterns to suit specific applications
- Light Bar in 50″ 8-Ring LIGHT PERFORMANCE
- Raw Lumens: 50″ = 18,400 lm
- Lux @ 10 Meters: 50″ = 6,700 lx
- Candela: 50″ = 670,000 cd
- Beam Distance (Meters): 50″ = 1,637m
SPECIFICATIONS
- Wattage: 50″ =160W
- Amp Draw: 5.0-14.67A
- LED Source: Cree XPL HD LED
- LED Color: 5000K
- Voltage: 9-32V
- IP Rating: IP68 – Dimensions: 50″ 8-Light = H – 6.06″ x D – 3.33″ x W – 51.625″
PARTS INCLUDED
- (2) Jeep Wrangler JL / Gladiator JT Overhead Light Bar Mounting Brackets (driver and passenger sides)
- (2) Jeep Wrangler JL / Gladiator JT Add-On, A-Pillar Light Mounting Tabs
- (1) Gravity® Pro6 LED Light Bar
- (8) Light Covers; Black with Yellow KC Logo
- (1) Performance Plug-N-Play Wiring Harness with Illuminated LED Switch
